HD67624-A1

HD67624-A1
New 3-4 days
HD67624-A1
  • Stock: 3-4 days
  • Brand: ADF Web
  • Model: HD67624-A1
Based on 0 reviews. - Write a review
2 351,44 zł
Add to Cart
Ask the expert!
Add to Wish List Compare this Product

Industrial S7comm to CANopen converter, type A plastic housing (narrow), DIN rail mounting, Ethernet and CAN ports

The HD67624-A1 model is an industrial converter equipped with a DIN rail mounting function 35mm. The operating temperature range from -40°C to +85°C allows the device to be used even when implementing projects in difficult industrial conditions. This model requires a power supply range of 8-24 VAC; 12-35 VDC.

Specification:

  • Ports: 1xCAN, 2xEthernet
  • Ethernet protocol: S7comm
  • CANopen protocol: CANopen
  • S7comm data transfer rate: 100 Base-T Autosensing
  • CANopen data transfer rate: Up to 1Mbps
  • S7comm connector: RJ45
  • CANopen connector: 3-way 5mm screw terminal
  • Power connector: 2-pin 5mm terminal block
  • Power supply: 8..24 VAC; 12..35VDC
  • Operating temperature: -40°C/+85°C (-40°F/+185°F)
  • Dimensions: 120x23x107 (length x width x height)
  • Weight: approx. 200g
  • Mounting: mounting on a 35 mm DIN rail
  • SOFTWARE: SW67624
  • ORDER CODE: HD67624-A1

Configuration – software SW67624 FREE DOWNLOAD

General technical parameters
Ethernet 2x 100BaseT(X)
Protocol support CANopen, S7comm
Industrial grade
Casing Plastic
IP rating IP20
Operating temperature -40°C to 85°C
Input voltage 8~24 VAC, 12~35VDC
Manufacturer's warranty 24 months
