HD67701-4-0-H5S
3-4 days
Industrial RS485 to single mode fiber optic converter, point to point & single loop connection, DIN rail mount.
Point-to-Point connection between two devices/networks over optical fiber. Optimal solution to cover a long distance, isolate the two sides and when there is the necessity to pass near noise sources (engines, inductive loads, etc.).
Single Loop connection between more converters. This solution is ideal where there is the necessity to connect/isolate over optical fiber different brenches/devices of existing systems.
Specification:
- Ports: 1x RS485; 1x USB; 1x Optic Fibers
- Data Rates RS485: Up to 115200 bps
- RS485 connector: 3way 5mm fixed screw terminal
- Optic Fiber connector: SFP (LC connector included)
- Power supply: 9...19VAC; 12...35VDC
- Operating temperature: -40°C to +85°C (-40°F/+185°F)
- Dimensions: 71 mm x 60 mm x 95 mm (DxWxH)
- Weight: 200g approx
- Mechanical fixing: DIN Rail mount
- Software: SW67701
- ORDER CODE: HD67701-4-0-H5S
Configurator – Software SW67701 FREE DOWNLOAD
General technical parameters | |
USB | 1x USB 2.0 |
Serial port | 1x RS-485 |
Fiber mode | Single-mode |
Fiber | 1x 10/100Base (SFP) |
Industrial grade | |
Operating temperature | -40°C to 85°C |
Input voltage | 9~19VAC, 12~35VDC |
Manufacturer's warranty | 24 months |
Mount | DIN rail |
