F-NR100

Product features:

Industrial-grade application design

• Using high-performance industrial-grade wireless module
• Using high-performance industrial-grade 32-bit communication processor
• Support low power consumption modes, including sleep mode, timing online and offline mode
• Using metal case, protection grade IP30.
• Metal housing and system are safely isolated, especially suitable for industrial
• control field applications
• Wide power input (DC 5 ~ 36V)

Stability and Reliability

• WDT watchdog design to ensure system stability
• Ethernet interface with built-in 1.5KV electromagnetic isolation protection
• SIM / UIM card interface with built-in 15KV ESD protection
• Power interface with built-in reverse protection and overvoltage protection
• Lightning protection of antenna interface (optional)

Standard and Convenience

• Provide standard RS232 (or RS485/RS422), Ethernet and WIFI interfaces, which can directly connect serial devices, Ethernet devices and WIFI devices
• Provide standard wired WAN port (support standard PPPOE protocol), which can be directly connected to ADSL equipment
• Intelligent data terminal, you can enter data transmission state after power on
• Provide powerful central management software to facilitate equipment management (optional)
• Easy to use, flexible, multiple working mode selection

Functions

• Support multiple WAN connection methods, including static IP, DHCP, PPPOE, 3G / UMTS / 4G / LTE, dhcp-4G
• Support LTE / EVDO and wired WAN dual link intelligent switch backup function (optional)
• Support VPN client (PPTP, L2TP, IPSEC) (Note: Only supported by VPN version)
• Support VPN sever (PPTP, L2TP, IPSEC) (Note: Only supported by VPN version)
• Support remote management, SYSLOG,
• SNMP, TELNET, SSHD, HTTPS and other functions
• Support local and remote online upgrade, import and export configuration files.
• Support NTP, built-in RTC.
• Support a variety of DDNS at home and abroad.
• WIFI supports 802.11b / g / n / ac, supports WIFI AP, AP Client, repeater, relay bridge and other working modes (optional)
• Support a variety of online and offline trigger modes, including SMS, phone ringing, serial data, network data trigger online and offline modes
• Support APN / VPDN
• Support multi-channel DHCP server and DHCP client, DHCP bundled MAC address, DDNS, firewall, NAT, DMZ host, QoS, traffic statistics, real-time display data transmission rate and other functions
• Support TCP / IP, UDP, FTP (optional), HTTP and other network protocols
• Support SPI firewall, VPN traversal, access control, URL filtering, and other functions.
• Timed online and offline functions.

Product specification

F-NR100 LTE-NR WIFI Router

• Standard Band:
  • 5G NR: n1/n2/n3/n5/n7/n8/n20/n28/n41/n66/n71/n77/n78/n79
  • LTE:B1/B2/B3/B4(66)/B5(18/19/26)/B7/B8/B12(17)/B13/B14/B20/B25/B26/B28/B29/B30/B38/B39/B40/B
  • 41/B42/B43/ B46/ B48/B71
• Bandwidth:
  • 5G NR：DL 3.4Gbps，UL 350Mbps
  • LTE Cat20：DL 2.0Gbps，UL 150Mbps
  • HSPA+：DL 42Mpbs，UL 5.76 Mbps
• Power: <23dBm
• Sensitive: <-97dBm

GPS

• GPS: GPS inside（optional）
• Type: 5 Hz
• Location:
  • 2.5m CPE
  • SBAS：2.0m CPE
• Sensitive:
  • Follow：-160dBm
  • Re-capture：-160dBm
  • Cold start：-146dBm

WIFI

• Standard Band:
  • IEEE802.11b/g/n，2.4G，AP mode，Station mode（optional）
  • IEEE802.11ac，5.8G，AP mode，Station mode（optional）
• Bandwidth:
  • IEEE802.11b/g：Bandwidth 54Mbps
  • IEEE802.11n：Bandwidth 150Mbps
  • IEEE802.11ac：Bandwidth 390Mbps
• Security: WEP、WPA、WPA2 encrption
• Power: 26dBm（11b），21.5dBm（11g），20dBm（11n），16dBm（11ac）
• Sensitive: <-72dBm@54Mpbs

Hardware

• CPU: Industrial 32 bit processor
• FLASH: Nor flah 16MB（64MB optional），nand flash 128MB
• DDR3: 512M
• TF: 8GB/32GB，optional

Interface

• WAN: 1 x 10/100/1000M Ethernet port（RJ45），auto MDI/MDIX，embeded 1.5KV ESD
• LAN: 4 x 10/100/1000M Ethernet port（RJ45），auto MDI/MDIX，embeded 1.5KV ESD
• Serial:
  • 1 x RS232 （or RS422/RS485)with 15KV ESD:
  • Databit：5、6、7、8
  • Stop bit：1、2
  • Baud rate: 2400 ~ 115200 bps
• Indicator: "PWR", "SYS", "WIFI", "SIM", "Online","Signal Strength"
• Antenna:
  • Cellur：6 x SMA ，50ohm
  • WIFI：2（4）x SMA, 50ohm
  • GPS：1 x SMA, 50 ohm
• SIM/UIM: Standard 3V/1.8V user card interface, 15KV ESD protection
• Power: Standard 3-PIN power jack, reverse-voltage and overvoltage protection
• RST: Restore the router to its original factory default settings
• Standard: DC 12V/1.5A
• Range: DC 5~36V
• DDR3: 512M
• Current: <700mA (12V)

Physical

• Box: Metal box，IP30
• Size: 140x200x40 mm
• Weight: 520g

Others

• Operating Temperature: -35°C~75ºC
• Storage Temperature: -40°C~85ºC
• Humidity 95%(unfreezing)

Order info:

• F-NR100: Cellular (5G NR), 2.4G/5G WIFI, SIM*1 , GPS(Optional)
